(25-75m³/h)The HZS stationary concrete batching plant is a fully automated system designed for efficient concrete production. Its modular structure allows for rapid installation and easy relocation.
Equipped with a high-performance twin-shaft mixer, the plant consistently produces a variety of concrete types with uniform quality. An integrated PC+PLC automatic control system ensures precise batching and real-time monitoring, delivering weighing accuracies within ±2% for aggregates and ±1% for cement and water.
Selecting the appropriate model depends primarily on your project's required concrete output. Smaller models like the HZS25 or HZS35 are cost-effective for rural or small municipal projects. In contrast, large-scale infrastructure such as high-speed rail hubs or major dams would require high-capacity models like the HLS120 or HLS180
| Name of parameters | HZS25 | HZS40 | HZS50 | HZS75 |
| Theoretical productivity | 25m³/h | 35m³/h | 50 m³/h | 75 m³/h |
| Model of mixer | JS500 | JS750 | JS1000 | JS1500 |
| Mixing motor power | 18.5kw | 30kw | 2x18.5kw | 2x30kw |
| Cycle period | 72s | 72s | 72s | 72s |
| Volume of mixer | 500l | 750l | 1000l | 1500l |
| Aggregate max size | ≤80mm | ≤80mm | ≤80mm | ≤80mm |
| Suppose volume of cement silo - OPTIONAL | 2x100t | 2x100t | 3x100t | 3x100t |
| Capacity of batching machine | 800l | 1200l | 1600l | 2400l |
| Volume of batching machine | 3x4 m³ | 3x4m³ | 3x6 m³ | 3x8 m³ |
| Quantity of aggregate | 3 | 3 | 3 | 3 |
| Conveyor ability of aggregate belt | 100t/h | 150t/h | 200t/h | 250t/h |
| Max. Conveyor ability of screw conveyor | 40t/h | 40t/h | 80t/h | 80t/h |
| Unloading height | 1.6m | 3.8m | 4.0m | 4.0m |
| Total power of the plant | 55kw | 75kw | 105kw | 150kw |
